Infrastructure and Facilities

Lab Name : Lab1 - Mechanics and Electronics

Title Details
Lab Area : 30’ x 30’
Lab Incharge Name :
Lab Attendant : Mr. Shivaji R. Padavi
Lab Instruments :
  • 1. Ultrasonicator 750 watt (Sonics)
  • 2. UV Spectrophotometer (Shimazdu) with attachment for Solid substrate sample
  • 3. Spin Coater
  • 4. Electric Furnace with Temperature controller
  • 5. Electric Digital Balance
  • 6. High Voltage Power Supply (60V/5A)
  • 7. Gas Sensing Unit
  • 8. Keithley Multimeter
  • 9. Motorized Pallet Press Machine
  • 10. Lab High Pressure Autoclave System
  • 11. Potentiostat
  • 12. Hydrothermal System
  • 13. Hot Air Oven
  • 14. Ultrasonic Bath (1.5 Ltr)
  • 15. Ultrasonic Bath (3.5 Ltr)
  • 16. Chemical Bath Deposition (CBD) Apparatus
  • 17. Four Probe Apparatus
  • 18. Hall Effect Kit
  • 19. Programmable Power Supply
  • 20. Photocatalytic Chamber
  • 21. HeatingSystemwith Temperature Controller
  • 22. DielectricConstantApparatus
  • 23. MagneticStirrerwithpHMeter
  • 24. HPComputer
  • 25. IRLamp
  • 26. MagneticStirrer

Lab Photos :

Lab Name : Lab2 - Research Laboratory

Title Details
Lab Area : 15’ x 30’
Lab Incharge Name : Mr. Alkesh C. Bhavsar
Lab Attendant : Mr. Shivaji R. Padavi
Lab Instruments :
  • CBD Setup
  • Flux method setup
  • Spin Coater
  • Hydrothermal setup

Lab Photos :

Lab Name :

Title Details
Lab Area : 15’ x 15’
Lab Incharge Name :
Lab Attendant : Mr. Shivaji R. Padavi
Lab Instruments :
  • Optical Bench
  • Laser set up
  • Spectrometer
  • Newton’s Ring setup

Lab Photos :

Lab Name :

Title Details
Lab Area : 15’ x 15’
Lab Incharge Name : Dr. A. A. Patil
Lab Attendant : Mr. Shivaji R. Padavi
Lab Instruments : 12 Computers with latest configuration

Lab Photos :

Lab Name :

Title Details
Lab Area : 900 Sq. Ft.
Lab Incharge Name : Dr. S. G. Bachhav
Lab Attendant : Mr. Amol Mistari
Lab Instruments :
  • Cathode Ray Oscilloscope
  • Digital Storage Oscilloscope
  • Power Supply
  • Programmable Power Supply
  • Signal Generator
  • Table top DMM
  • Frequency Counter
  • IC Tester
  • Desktop Computers
Practical’s performed in Lab :
  • Network Analysis
  • Electronic Devices & Circuits
  • Analog Circuits
  • Digital Circuits
  • Analog Communication
  • Digital Communication
  • Microprocessor
  • Microcontroller
